A. Adopted low consumption CPU
B. Adopted unique Mutil codes
C. Auto status report
D. Anti-lost report
E. Open door/window indication
①Wireless sending distance(open area):inset antenna 150m.
②Code: 28-digi t ID, 8-digit function code, 36 digits data code in total
③Working frequency: 433MHz/868MHz(optional)
④Working voltage:3V lithium battery
⑤Battery life: about 1 year
⑥Current: static ≤5uA, alarm:7-12mA (433MHz),static ≤5uA, alarm:35-45mA (868MHz)
⑦ Alarm output: alarm, tamper
⑧Status report：after fist electro motion or reset the
detector the magnetic switch report the working status
to the control panel separately after 30 seconds, 2
minutes,6minutes. And report working status every
two hours to the control panel.
⑨Working Temeprature:-10℃~50℃
⑩Dimesion:81(L)*32(W)*25(H)mm, Magnetic stripe:74.5 (L)*13.5(W)*18.8(H)mm
11.Color: White
