◎ Reliable detection performance with quad PIR technology；
◎ Excellent false alarm prevention with look-down window to avoid blind-corner；
◎ Detection distance：9m@25℃
◎ Detection angle：110°
Model：PE-81R DMT
Detection range：９m（25℃）
Emitting distance：120-150m（in the open area）
Input voltage：3VDC（model CR123A lithium battery）
Current consumption： Static≤30μA，Alarm≤12mA（433MHz）, Static≤30μA，Alarm≤50mA（868MHz）
infrared area(as shown )
Optical lens data
detection angle：1100
emitting frequency：433MHz/868MHz
Alarm indication：LED flashes 2 seconds.
Mounting:
Surface or corner, at the height of 2.0 to 2.4m
Note: Base allows single-sided corner mount at 45detection method:PIR & MW
power supply: 6 VDC
battery life: about 1 year
coverage: 8*8m / 90?
alarm indication:4~5s
start up time: 30s with LED indication
working range: max. 150 m (open area)
white light protection:4000 lux
working freguency: 433MHz
environmental:-10℃ to +40℃
demision:110*95*49mm
Installation
installation height from 1.8 to 2.4m allow an 45° angle between the wall bracket optional to wall
operation condition：
Operating Temperature: -100C to- 500C(140F to 1220F )
Storage Temperature :-200C to -600C (-40F to 400F)
Anti white light interference: 9000 LUX (indoor)
Size: (L*W*H)95*64*49mm
