◎Slim and elegant design, fit for various environment
◎Anti-interference of insects or dust and anti-white light with sealed optics design
◎Adopts self-designed MASK chip with DMT technology
◎Dual infrared FRESNEL lens with Look-down window to avoid blind-corner design
◎Advanced pet-immunity recognition technology can tell the difference between the an intruder and a pet.
◎Stable performance with tamper supervised, low-voltage check and status report function
◎Digital Auto pulse count adjustable, Auto temperature compensation and energy analysis
◎Lower power consumption, built-in big capacity batteries, special low-power mode, ultra-long working hours.
Detection distance：９m（25℃）
Emitting distance：120-150m（in broad area）
Input voltage：3VDC（123A Lithium battery）
Quiescent current：9μA
Emitting current：4.5mA
Infrared section(as shown in the figure)
Optical lens data
Infrared area：11+5 （typical）
Max.coverage：9 m*9m (23*46feet)/90°
Emitting frequency：433MHz
Alarm indication：LED flashes for seconds.
Installation：
Wall or corner mountable，1.8-2.5m(6-8ft)above
ground
Operating environment：
Operating temp：-10℃-50℃（14℉-122℉）
Storage Temp.：-20℃-60℃（-4℉-140℉）
Anti-white light（indoor）：>9000LUX
Dimensions:（L*W*H）112*59*41mm
