◎ Passive infrared+MW+ Artificial Intelligence ,Passive/active infrared+MW+ Artificial Intelligence are optional.
◎ PIR detection technology, adopts Infrared obstruction detecting motion.
◎ MW adopts measurement principle to detect motion.
◎ Germany import optical filter which can block other light up to 99%;the lens special for anti-UV.
◎ Fully sealed design.
◎ Detection distance：3m@25℃
◎ Detection angle：20°
Detect distance:3m
Input Voltage：9-15VDC
Consume current：DC12V@12-15mA
PIR part(as right fig.)
Optics lens data:
PIR range：18*2（Normal）
Maz.coverage：3m*2m/90°
Alarm output：solid relay,N.C.
<100mA/30V,--10Ω inner resistance
Alarm indicator：red LED light
Mounting：
Please mount it on the wall up window
Working condition：
Working temperature：-10℃-50℃（14℉-122℉）
Storage temperature：-20℃-60℃（-4℉-140℉）
Anti white light（indoor）：>9000LUX
Anti-RF/EMI:>30V/M，10MHz-1000MHz
Dimension:（L*W*H）230*66*36mm
