Model |
DT-8250 |
DT-8250DMF |
DT-8250DMT |
|
Detection |
quad infrared+MW |
quad infrared+MW |
quad infrared+MW |
|
MW frequency |
10.525GHz |
10.525GHz |
10.525GHz |
|
Working voltage |
9～16VDC |
9～16VDC |
9～16VDC |
|
Working current |
8mA～25mA |
8mA～25mA |
8mA～25mA |
|
Automatic Temperature Compensation |
★ |
★ |
★ |
|
pulse counting adjustable |
★ |
★ |
★ |
|
tamper alarm |
★ |
★ |
★ |
|
Alarm output |
N.C，50mA/30VDC |
N.C，50mA/30VDC |
N.C，50mA/30VDC |
|
tamper interface |
N.C，50mA/30VDC |
N.C，50mA/30VDC |
N.C，50mA/30VDC |
|
pet-immunity |
|
25kg |
25kg |
|
anti- cloak |
|
Yes |
|
|
Anti-white light |
>9000LUX |
>9000LUX |
>9000LUX |
|
Installation mode |
Wall-mounted |
Wall-mounted |
Wall-mounted |
|
Installation height |
1.8m-2.4m |
1.8m-2.4m |
1.8m-2.4m |
|
Dimension |
136×60×48mm |
136×60×48mm |
136×60×48mm |
