Model |
MC-800 |
MC-800DMT |
|
Detection |
Quad infrared |
Quad infrared |
|
Working voltage |
9～16VDC |
9～16VDC |
|
Working current |
8mA～25mA |
8mA～25mA |
|
Automatic Temperature Compensation |
★ |
★ |
|
pulse counting adjustable |
★ |
★ |
|
Status report |
★ |
★ |
|
tamper alarm |
★ |
★ |
|
Alarm output |
N.C，50mA/30VDC |
N.C，50mA/30VDC |
|
tamper interface |
N.C，50mA/30VDC |
N.C，50mA/30VDC |
|
pet-immunity |
|
25kg |
|
Anti-white light |
>9000LUX |
>9000LUX |
|
Installation mode |
Wall-mounted |
Wall-mounted |
|
Installation height |
1.8m-2.4m |
1.8m-2.4m |
|
Dimension |
92 * 61 * 44 mm |
92 * 61 * 44 mm |
