Model
|
BX-3050/B
|
BX-3100/B
|
BX-3150/B
|
BX-3200/B
|
BX-3250/B
|
|
Outdoor detection distance
|
50m
|
100m
|
150m
|
200m
|
250m
|
|
Indoor detection distance
|
150m
|
300m
|
450m
|
600m
|
750m
|
|
Number of beams
|
3
|
||||
|
Response speed
|
35～700m/s
|
||||
|
Alarm output-normal
|
Normally close and normally open（NC&NO）contact capacity AV/DC 30V/0.5mA
|
||||
|
Alarm linkage
|
√
|
||||
|
Working voltage
|
DC8～36V；AC8～20V
|
||||
|
Working current
|
60mA
|
65mA
|
65mA
|
65mA
|
70mA
|
|
Long-life mode
|
40mA
|
32mA
|
32mA
|
32mA
|
40mA
|
|
Environment
|
temperature:-25℃～65℃ ； humidity:5%—95% (RH)
|
||||
|
Tamper output
|
Normally close(NC) contact capacity AV/DC 24V/0.5mA
|
||||
|
Adjust angle
|
Horizontal:180°(±90°) ； Vertical:±10°
|
||||
|
Case material
|
Germany PC
|
||||
|
Remark
|
The end with “B” is BUS output system
|
||||
