| Model |
BX-2030/B
|
BX-2060/B
|
BX-2080/B
|
BX-2100/B
|
|
Outdoor detection distance
|
30m
|
60m
|
80m
|
100m
|
|
Indoor detection distance
|
80m
|
180m
|
240m
|
300m
|
|
Number of beams
|
2
|
|||
|
Response speed
|
50～700m/s
|
|||
|
Alarm output-normal
|
Normally close and normally open（NC&NO）contact capacity AV/DC 30V/0.5mA
|
|||
|
Alarm linkage
|
√
|
|||
|
Working voltage
|
DC8～36V；AC8～20V
|
|||
|
Working current
|
40mA
|
55mA
|
65mA
|
65mA
|
|
Long-life mode
|
20mA
|
30mA
|
35mA
|
35mA
|
|
Environment
|
temperature:-25℃～65℃ ； humidity:5%—95% (RH)
|
|||
|
Tamper output
|
Normally close(NC) contact capacity AV/DC 24V/0.5mA
|
|||
|
Adjust angle
|
Horizontal:180°(±90°) ； Vertical:±10°
|
|||
|
Case material
|
Germany PC
|
|||
|
Remark
|
The end with “B” is BUS output system
|
|||
