Video Function
*Video access:4*AHD/4*960P/4*1080P（EAVS-2504）
8*AHD/8*960P/8*1080P（EAVS-2508）
*Synchronous playback:2*AHD/4*960P/2*1080P（EAVS-2504）
4*AHD/6*960P/4*1080P（EAVS-2508）
*Video Output:HDMI/VGA/IVDEO output.
*Capability:Preview/Recording/Playback/backup/Network Monitoring.
*Network Protocol:TCP/IP, DHCP, DDNS,PPPoE.
*Network Security:IP filter, Password Authentication.
*IPC Protocol:onvif 28181.
*Motion detection alarm and detector intrusion alarm dual identification.
*Support 3G mobile video monitoring, and PTZ/Home appliance control.
*Support video and data directional transmission,facilitate networking.
*Support P2P Server.
Alarm Function
*Capacity:4 wired+32 wireless+64 bus zones+16CH electric switch control.
*Arm/Disarm mode:whole arm/disarm, 8 partition arm/disarm, sole arm/disarm.
*Network communication:PSTN+GPRS+TCP/IP Triple in one.
*Tel-line communication:2 CMS No. 4 voice phone No. 2 free charge of arm/disarm No.
*GSM communication:4 voice phone No. GSM SMS arm/disarm, GPRS network communication.
*IP communication:IE program, remote upgrade,remote control, alarm networking.
*Remote program:GPRS TCP/IP dual data transmission remote program.
*Distinct function: voice prompt. Intercom, site monitoring, timing arm/disarm, online/offline report, Environmental monitoring. Smart home appliance.
*Extended function:relay linkage, PGM output.
|
Product Name
|
EAVS-2504/8(Hi3520d)
|
|
Operating System
|
Embedded Linux
|
|
User Interface
|
16bit true color graphical menu operation interface
support USB mouse operation with menu notes
|
|
Peripheral Interface
|
Video Input
|
4/8 channel BNC video input
|
|
Audio Input
|
4/8 channel RCA audio input
|
|
Audio Output
|
1 channel 3.5mm audio output
|
|
Video Output
|
1 channel VGA output / 1 channel BNC output / 1CH HDMI output
|
|
PC Output
|
1 channel VGA output
|
|
Alarm Input
|
8 wired zones, 32 wireless zones, 64 bus zones.
8 wireless remote control, 16 wired keypad. 16CH electrical power switch.
|
|
RS485 Port
|
1 RS487 port
|
|
Network Interface
|
1 RJ45, 10M/100M adaptive network interface
|
|
HDD Interface
|
2 SATA HDD interface
|
|
Mouse port
|
1 USB2.0 port
|
|
USB port
|
1 USB2.0 / 1 USB1.1 port
|
|
Antenna port
|
1 x 6 PINS port
|
|
Telephone Line port
|
1 in / 1 out, 2 groups of terminal port
|
|
Power Interface
|
1 DC12V input
|
Audio/Video
Parameters
|
Monitor Resolution
|
1024*768/60hz, 1280*720/60hz, 1280*1024/60hz, 1600*1200/60hz, 1920*720p/60hz, 1920*1080p/60hz
|
|
Playback Resolution
|
1024*768/60hz, 1280*720/60hz, 1280*1024/60hz, 1600*1200/60hz, 1920*720p/60hz, 1920*1080p/60hz
|
|
Video Coding Standard
|
H.264, PAL / NTSC
|
|
Video Output Rate
|
960H, 1080p, 720p. (adjustable)
|
|
Audio Coding Standard
|
ADPCM,sampling rate,8khz / 8bit
|
|
Audio Output Rate
|
24Kbps
|
