P2P Cloud Server Free Usage
Now you can have a WIFI+GSM Alarm system which you can control from anywhere in the world. free download your mobile APP, No need to set up static IP address or configure the nework connection on-site. Just scan the QR code from the host panel sticker, directly remote Arm/Disarm, checking the system status and setting up notifications, video cameras on-site seeing. you can now have ultimate control of your home security whenever required.
The Host with 2G/4G, WIFI(2.4g). one key connect to the home router WIFI . 2G/4G network for backup network.
With 8 WIFI Cameras
From the APP, users can scan the QR code from the wifi cameras for 8 PCS, users can review the video at anytime, anywhere. It can snap the alarm picture, backup the alarm video to your smartphone.
SIA-TCP, SIA-UDP, Meian Private IP protocol
Support SIA-UDP, TCP Global standard Protocol. More effective docking way to compatible with customers CMS platform.
| Art No.: | HA-IIIGW |
| Dimensions | 200*140*15MM |
| Housing Materials | ABS Plastic+Tempered Glass Surface |
| Installation Location | Indoor Use Wall Mounted |
| LCD Display | Graphic display, status light |
| Menu Voice Guidance | YES |
| Kit Weight | 1.20KG |
| Kit Accessories Included | |
| 1*Wireless PIR Detector | |
| 1*Wireless Door Sensor | |
| 2*Wireless Remote Controller | |
| 2*RFID tags | |
| System Network | 2G/4G WIFI(2.4G) |
| Number Of Users | 16 |
| Number Of Wired Zones | 0 |
| Number Of Bus Zones | NO |
|
Number Of Wireless Remotes Or Wireless Keypad Controls |
8 |
| Number Of Wired Keypad | 0 |
| Number Of Wireless Zones | 64 |
| Number Of Voice Phones | 4 |
| Number Of Wireless Doorbell | 1 |
| Number Of Wireless Switch | 16CH |
| Number Of Wireless Siren |
Dual Way Siren *1 One Way Siren No Limited |
| Outputs | NO |
| 2G/4G Antenna | Internal 2G/4G Antenna |
| Event Log Inquiry | 512 |
| Radio Frequency | 433MHz or 868MHz |
| Intergrated Siren | YES(85Db@1M) |
| Backup Battery Type | 12V DC, 7AH Lead Acid Battery |
| Max Receiving Range | 150M |
| Max Sending Range | 100M |
| Power Supply Unit | 5V/2A |
| Protocols | Ademco Contact ID |
| Tamper Monitoring | YES |
| Mobile Client |
ST-Panel http://www.meiantech.com/en/Support/download/
|
| WebIE | YES |
| Meian CMS | Server: wode110.com |
| Tel-Line CMS | 2 CMS |
| Certifications | CE/FCC/ROHS |
